PHYSICAL CHARACTERISTIC
Dimensions (HxWxD):
Apex 2: 135 x 103 x 60 mm (5.1 x 4.1 x 2.4 in)
Apex 3: 156 x 127 x 58 mm (6.1 x 5.0 x 2.3 in)
Apex 4: 191 x 166 x 63 mm (7.5 x 6.5 x 2.5 in)
Weight:* 0.42 kg (14.7 oz); 0.52 kg (18.5 oz);
0.75 kg (26.5 oz)
Weight:** 0.53 kg (18.7 oz); 0.75 kg (26.5 oz);
1.02 kg (36.1 oz)
Drop Specification: 1.2 m (4 ft)
*With battery
**With battery and paper roll
USER ENVIRONMENT
Operating Temperatures: -10°C to 50°C
(14°F to 122°F)
Storage Temperatures: -20°C to 60°C
(4°F to 140°F)
Charging Temperatures: 5°C to 40°C
(41°F to 104°F)
Relative Humidity Range: 10% RH to 85% RH
non-condensing
ESD Protection: 8kV air gap, 4kV contact
PRINT TECHNOLOGY
Printhead: Direct Thermal; 8 dots per mm
(203 dots per in)
Print Mechanism Speed: 51 mm per second
(2 in per second)
COMMUNICATION
Serial: (Apex 2 and Apex 3 only),
RS232, up to 115.2 kbps
USB: 2.0 (Apex 3 and Apex 4 only)
Bluetooth® (Class 1): Version 2.1
IrDA: IrLPT v1.0; IrCOMM v1.0
MEDIA
Media Type: Direct thermal receipt paper (standard,
premium, heavy duty, long-life, image protect, hitemp, and all weather)
For optimum print quality and printer
performance, use certified Honeywell media
supplies.
AGENCY APPROVAL
Contact your Honeywell sales representative for
the most recent list of agency approvals.
BARCODES/FONTS/GRAPHICS
Linear Symbologies: Codes 39, Code128 A/B/C,
UCC/EAN-128, Interleaved2 of 5, UPC/EAN/JAN and
Codabar, GSI Databar, Code 93
2D Symbologies: PDF417, QR Code
Optional Characters: Simplified & traditional
Chinese, Hebrew, Arabic, Polish, Greek, Cyrillic, Thai,
Vietnamese, Hagul (Korean)
Graphics: Supports 8-bit graphic printing, custom
font, logo downloading
Standard Fonts: ASCII, International, PC line draw:
12CPI, 16CPI, 19CPI, 21CPI, 24CPI, 13CPI rotated
SOFTWARE/FIRMWARE
Configuration Utility Includes: Firmware upgrade,
font download, Bluetooth® set-up, communications
parameter set-up; printer custom attributes set-up,
logo download
Drivers: Windows, CE and Desktop
Form Fiesta Page Printing Utility
Bootloader for Uploading Firmware
OPTIONS
Bluetooth® or IrDA
Integrated Magnetic Stripe Card Reader
WARRANTY
Standard Warranty:
Printer: 1 year*
Printhead: 1 year* or 25,400,000 mm (1,000,000 in),
whichever comes first)
Extended Warranty: Contact your Honeywell
sales representative for extended warranty options
available through Honeywell Repair Services
Features
- MS DOS and Windows compatible. Print utilities and drivers available for most systems.
- Apex printers are light enough to wear all day, everyday and small enough that they don’t hinder movement.
- Supported by Arm-7, 32-bit architecture RISC processor, making them as fast as printers costing almost twice as much.
- Shipped with a battery, power supply, belt clip or shoulder strap, sample media and RS232 or USB wireless communications.
- Supports the printing of graphics, 1D and 2D bar codes.
