ArborElectro Impedance Tomograph
Specification
| Excitation Voltage |
5–50 V, adjustable in 5 V steps |
| Current Measurement Range |
0–20 mA;
0–400 µA;
0–40 µA |
| Length of One Basic Measurement |
640 ms |
| Amplifications |
1, 5, 20, 100 |
| Inbuilt Divider |
1:10 |
| Power Supply |
Built-in 5 V / 5000 mAh Li-ion Power Bank |
| Continuous Operation Time* |
Approximately 2 hours |
| Total Weight** |
6 kg |
| PC Connection |
LEMO-USB cable or Bluetooth |
| Total Measurement Time of One Tree*** |
45 minutes |
| Operating Temperature Range |
0–40 °C |
