Specifications
Standard Ranges : 7, 17, 35, 70, 170, 350, 700 kPa;
1, 2, 3, 5, 7.5, 10, 20, 25, 35, 50, 75, 100, 150 MPa
1, 2, 3, 5, 7.5, 10, 20, 25, 35, 50, 75, 100, 150 MPa
Over Range : 1.5 × rated pressure
Resolution¹ : 0.025% F.S. (minimum)
Accuracy : ±0.1% F.S.
Linearity : <0.5% F.S. (±0.1% F.S. optional)
Temperature Range² : −20°C to +80°C
Length × Diameter : varies according to pressure range
¹Depends on readout system.
²Other ranges available on request.
