Technical SpecificationsNote2
| Specifications | C611M |
|---|---|
| Load Cell Capacity | 9KN (3 pcs) |
| Accuracy | Indicated Value ±1% (10% ~ 100% of load cell capacity) ±0.1% FS (0% ~ 10% of load cell capacity) |
| Force Resolution | 1 N |
| Deformation Resolution | 0.1 mm |
| Test Speed | 0 ~ 200 mm/min (Any integer within the specified range) |
| Speed Accuracy | Indicated Value ±2% |
| Stroke | 450 mm |
| Specimen Height | 0 ~ 600 mm |
| Test Space | 0.8 m (L) × 0.8 m (W) × 0.61 m (H) |
| Instrument Dimension | 0.85 m (L) ×1.01 m (W) × 1.66 m (H) |
| Power Supply | AC220V±10% 50Hz / AC120V±10% 60Hz |
| Net Weight | 245 kg |
Configurations
- Standard Configurations
- Instrument, Monitor, Mouse, Keyboard, Printer (Inkjet), 150mm Plate (1pcs)
- Optional Parts
- Auxiliary Metering Device, GMP System, DataShieldTM Note3
Note 1: The described test standard, applications and product features should be in line with Technical Specifications.
Note 2: The parameters in the table are measured by professional operators in Labthink laboratory under strictly controlled laboratory conditions.
Note 3: DataShieldTM provides safe and reliable data application support. Multiple Labthink instruments can share one single DataShieldTM system which can be configured as required.
