Features
| ● Advanced micro-electronic technology for wide range metal hardness test
● Simple menu, easy and convenient to use ● Conversion of common hardness scales (HL, HV, HB, HRC, HRB, HRA and HS) & conversion to Tensile Strength ● 7 types of optional impact devices, with auto recognition. Universal standard impact device D included. ● 2.8 inches TFT LCD screen, 240 X 320 dot Matrix, 262K color display with adjustable back-light showing all the important values and information ● Memory of 1000 groups of data ● Upper /lower limits setting and sound alarm ● Transfer to PC via USB in Word & Excel format , with Powerful PC Software included ● Indication for charge and life-long rechargeable Li battery without memory ● Removable printer optional and test values can be printed directly ● Built-in conversion table and HB value can be read directly if D/DC impact device installed |
Specification
| Measuring range | (170-960)HLD |
| Tolerance and repeatability | tolerance: |
| ±6HLD (790±40HLD) | |
| repeatability: | |
| 6HLD (790±40HLD) | |
| Measuring direction | 360 º |
| Hardness scale | HL, HB, HRA,HRB, HRC,HV, HS |
| Display | 2.8 inch TFT LCD screen,240 x 320 dot matrix,262K color display |
| Data storage | 1000 groups of data |
| Upper and lower limits setting | (170-960)HLD |
| Working voltage | 3.7V |
| Charging time | 6 hours |
| Power | 12V/500mA |
| Continuous working time | 20 hours |
| Interface | USB2.0 |
| Standard Delivery | Optional Accessory | |
| Main unit | 1 | Impact device: DC, D+15, C, G, DL |
| Impact device type D | 1 | Support rings |
| Test block HLD | 1 | Dataview |
| Small support ring | 1 | |
| Charger | 1 | |
| Cleaning brush | 1 | |
| Thermal printer paper | 1 | |
| TIME certificate | 1 | |
| Warranty card | 1 | |
| Hardness tester manual | 1 |
