● Simple menu, easy and convenient to use.
● Conversion of common hardness scales (HL, HV, HB, HRC, HRB, HRA and HS) & conversion to tensile strength.
● 7 types of optional impact devices with auto recognition. Standard impact device D included.
● Matrix LCD display with backlight showing all the important values and information.
● Memory of 48-350 groups of data.
● Upper /Lower limits pre-setting and sound alarm.
● RS232 connector meets more needs like storage and further analysis.
● Indication for charge and easy change for rechargeable battery.
● Printer included and test values can be printed directly.
Specification
|
Measuring range |
(170-960)HLD (17.9-69.5)HRC |
|
Hardness scale |
HL, HB, HRA, HRB, HRC, HV, HS |
|
Measuring direction |
360° |
|
Tolerance |
±6HLD(when HLD=760±30) |
|
Repeatability |
6HLD(when HLD=760±30) |
|
Diameter for printer paper |
40mm |
|
Width for printer paper |
44.5±0.5mm |
|
Power |
12V/600mA |
|
Charging time |
2-3.5 hour |
|
Humidity |
≤90% |
|
Operating temperature |
0℃~40℃ |
|
Dimensions (mm) |
234×88×46 |
|
Weight (g) |
600 |
| Standard Delivery | Optional Accessory | |
| Main unit | 1 | Printing paper |
| Impact device type D | 1 | Special impact devices |
| Test block HLD | 1 | Support rings |
| Small support ring | 1 | |
| Cleaning brush | 1 | |
| Charger | 1 | |
| TIME certificate | 1 | |
| Warranty card | 1 | |
| Instruction manual | 1 |
