● Added with roller hardness testing system.
● Simple menu, easy and convenient to use.
● Conversion of common hardness scales (HL, HV, HB, HRC, HRB, HRA and HS).
● 7 types of optional impact devices with auto recognition. Standard impact device D included.
● Matrix LCD display with backlightfor convenient use in darkness.
● Memory of 48-350 groups of data.
● Upper /Lower limits pre-setting and sound alarm.
● RS232 connector meets more needs like storage and further analysis.
● Software calibration.
● Removable printer included and test values can be printed directly.
● Conform to JB/T 9378-2001, Q/HD SDF006-2003 Standards.
Specification
|
Measuring range |
(30-110) HSD HLD |
|
Hardness scale |
HL,HB, HRA, HRB, HRC, HV, HS |
|
Measuring direction |
360° |
|
Tolerance |
±6HLD |
|
Repeatability |
6HLD |
|
Power |
12V/600mA |
|
Charging time |
2 hours (with over-charged protection) |
|
Operating temperature |
0°C-40°C |
|
Dimensions (mm) |
270x86x47 |
|
Weight (g) |
530 (including main unit and printer) |
|
Interface |
RS 232 |
| Standard Delivery | Optional Accessory | |
| Main unit | 1 | Printing paper |
| Impact device type D | 1 | Special impact devices |
| Test block HLD | 1 | Support rings |
| Charger | 1 | |
| Cleaning brush | 1 | |
| Table support for main unit | 1 | |
| Connecting cable | 1 | |
| TIME certificate | 1 | |
| Warranty card | 1 | |
| Instruction manual | 1 |
