Unduh Data via Bluetooth
Data logger kelas riset dengan biaya terjangkau untuk pemantauan berkelanjutan ketinggian muka air dan suhu, dengan kemampuan pengukuran hingga kedalaman 13, 30, atau 100 kaki, cocok untuk lingkungan air tawar maupun air laut.
| Operation Range | 0 to 207 kPa (0 to 30 psia); approximately 0 to 9 m (0 to 30 ft) of water depth at sea level, or 0 to 12 m (0 to 40 ft) of water at 3,000 m (10,000 ft) of altitude |
| Factory Calibrated Range | 69 to 207 kPa, 0° to 40°C 10 to 30 psia, 32° to 104°F |
| Burst Pressure | 310 kPa or 18 m depth 45 psia or 60 ft depth |
| Water Level Accuracy* | Typical error: ±0.1% FS, 1.0 cm (0.03 ft) Water Maximum error: ±0.2% FS, 2.0 cm (0.06 ft) Water |
| Raw Pressure Accuracy** | ±0.3% FS, 0.62 kPa (0.09 psi) Maximum error |
| Resolution | <0.02 kPa Water 0.007 ft Water |
| Pressure Response Time (90%)*** | <1 second at a stable temperature; measurement accuracy also depends on temperature response time |
| Operation Range | 0 to 400 kPa (0 to 58 psia); approximately 0 to 30.6 m (0 to 100 ft) of water depth at sea level, or 0 to 33.6 m (0 to 111 ft) of water at 3,000 m (10,000 ft) of altitude |
| Factory Calibrated Range | 69 to 400 kPa (10 to 58 psia), 0° to 40°C (32° to 104°F) |
| Burst Pressure | 500 kPa (72.5 psia) or 40.8 m (134 ft) Depth |
| Water Level Accuracy* | Typical error: ±0.1% FS, 3.0 cm (0.1 ft) Water Maximum error: ±0.2% FS, 6.0 cm (0.2 ft) Water |
| Raw Pressure Accuracy** | ±0.3% FS, 1.20 kPa (0.17 psi) Maximum error |
| Resolution | <0.04 kPa (0.006 psi), 0.41 cm (0.013 ft) Water |
| Pressure Response Time (90%)*** | <1 second at a stable temperature; measurement accuracy also depends on temperature response time |
| Operation Range | 0 to 145 kPa (0 to 21 psia); approximately 0 to 4 m (0 to 13 ft) of water depth at sea level, or 0 to 7 m (0 to 23 ft) of water at 3,000 m (10,000 ft) of altitude |
| Factory Calibrated Range | 69 to 145 kPa (10 to 21 psia), 0° to 40°C (32° to 104°F) |
| Burst Pressure | 310 kPa (45 psia) or 18 m (60 ft) Depth |
| Water Level Accuracy* | Typical error: ±0.1% FS, 0.4 cm (0.013 ft) Water Maximum error: ±0.2% FS, 0.8 cm (0.026 ft) Water |
| Raw Pressure Accuracy** | ±0.3% FS, 0.43 kPa (0.063 psi) Maximum error |
| Resolution | <0.014 kPa (0.002 psi), 0.14 cm (0.005 ft) Water |
| Pressure Response Time (90%)*** | <1 second at a stable temperature; measurement accuracy also depends on temperature response time |
| Operation Range | -20° to 50°C -4° to 122°F |
| Accuracy | ±0.2°C from 0° to 50°C ±0.36°F from 32° to 122°F |
| Resolution | 0.10°C at 25°C 0.18°F at 77°F |
| Response Time (90%) | 10 minutes in water (typical) |
| Stability (Drift) | 0.1°C per year 0.18°F per year |
| Wireless Standard | Bluetooth 5 LE |
| Transmission Range | Approximately 30.5 m (100 ft) line-of-sight |
| Radio Power | 1mW (0 dBm) |
| Real-time Clock | ±1 minute per month 0° to 50°C (32° to 122°F) |
| Battery | 2/3 AA, 3.6 Volt lithium, factory-replaceable |
| Battery Life (Typical Use) | 3 years with 1-minute logging and Bluetooth always on 7 years with 1-minute logging and Bluetooth off and LED off 10 years with 5-minute logging and Bluetooth off and LED off |
| Battery Indication | Battery status shown in HOBOconnect app (approximate) |
| Memory (Non-volatile) | Approximately 400,000 sets of pressure and temperature measurements |
| Data Download Time (with Bluetooth 5+ devices) | Approximately 3.5 minutes; 100,000 measurements < 1 minute |
| Weight | Approximately 154 g (5.43 oz) in air Approximately 53.9 g (1.9 oz) in fresh water |
| Dimensions | 3.18 cm (1.25 inches) diameter, 15.24 cm (6.0 inches) length; mounting hole 6.3 mm (0.25 inches) diameter |
| Wetted Materials | Polypropylene housing and lanyard; Viton and Buna-N O-rings; ceramic sensor in acetal end cap; stainless steel screws suitable for saltwater |
| Logging Modes | Fixed-interval (normal or statistics), burst or multiple intervals with up to 8 user-defined intervals and durations; logging intervals from 1 second to 18 hours. Refer to the HOBOconnect User’s Guide for details. |
| Start Modes | Immediate, next interval, date & time, button start (fob or app) |
| Stop Modes | Memory full, never stop (overwrite oldest data), date & time, or after set logging period |
| Pause | Pause and restart with HOBOconnect app |
| Alarms | Log high- or low-alarm events; alarm status shown in HOBOconnect app |
| Environmental Rating | IP68 |
