Overview

Data logger dengan Bluetooth
Alat pencatat suhu dan tingkat cahaya yang tahan air, dilengkapi Bluetooth untuk mengirim data akurat langsung ke HP atau komputer Windows melalui aplikasi gratis HOBOconnect.

Features

Sensor cahaya lebih akurat dan koneksi Bluetooth untuk transfer data.
Memori hingga 96.000 data, tahan air 30 meter, baterai bisa diganti.
Mudah dipasang, ada indikator LED, kompatibel dengan HOBOconnect.
Akurasi suhu ±0,5°C dan cahaya ±10%.

Specification

Temperature Sensor (MX2201 and MX2202)

Range	-20° to 70°C in air -4° to 158°F in air -20° to 50°C in water -4° to 122°F in water
Accuracy	±0.5°C from -20° to 70°C (±0.5°C from -4° to 158°F)
Resolution	0.04°C 0.072°F
Drift	<0.1°C per year (<0.18°F per year)
Response Time	17 minutes typical to 90% in air moving 1 m/s, unmounted 7 minutes typical to 90% in stirred water, unmounted

Light Sensor (MX2202)

Range	0 to 167,731 lux (0 to 15,582 lum/ft2)
Accuracy	±10% typical for direct sunlight (see Light Measurement on page 2 for more details)

Logger

Logger Operating Range	-20° to 70°C in air (-4° to 158°F in air)
Buoyancy (Fresh Water)	2 g positive (0.07 oz positive)
Waterproof	To 30.5 m (To 100 ft)
Radio Power	1 mW (0 dBm)
Transmission Range	Approximately 30.5 m line-of-sight (Approximately 100 ft line-of-sight)
Wireless Data Standard	Bluetooth Low Energy (Bluetooth Smart)
Logging Rate	1 second to 18 hours
Time Accuracy	±1 minute per month at 25°C (±1 minute per month at 77°F)
Battery	CR2032 3V lithium, user replaceable
Battery Life	1 year typical at 25°C (77°F) with logging interval of 1 minute and Bluetooth Always On enabled in software. 2 years typical at 25°C (77°F) with logging interval of 1 minute and Bluetooth Always On disabled in software. Faster logging intervals and statistics sampling intervals, burst logging, remaining connected with the app, excessive downloads, and paging may impact battery life. To ensure proper battery installation, see Battery Information for detailed instructions on replacing the battery.
Memory	96,000 measurements
Full Memory Download Time	Approximately 45 seconds; may take longer the farther the device is from the logger
Wetted Materials	Polypropylene case, EPDM O-ring
Dimensions	3.35 x 5.64 x 1.8 cm 1.32 x 2.22 x 0.69 inches
Weight	12.75 g (0.45 oz)
Environmental Rating	IP68
