HOBO Temperature/Relative Humidity 3.5% Data Logger

HOBO Temperature/Relative Humidity 3.5% Data Logger
HOBO Temperature/Relative Humidity 3.5% Data Logger - Image 2
HOBO Temperature/Relative Humidity 3.5% Data Logger - Image 3

Overview

Dilengkapi sensor terintegrasi untuk mengukur dan merekam suhu serta kelembapan relatif dengan tingkat akurasi hingga ±3,5%, cocok digunakan di lingkungan dalam ruangan.

Informasi Penting:
Memerlukan perangkat lunak HOBOware dan kabel USB untuk pengoperasian dan pengambilan data.
(Catatan: Kabel USB-A ke USB-B mini sudah termasuk dalam pembelian paket software HOBOware Pro USB Drive).
Silakan lihat daftar produk yang kompatibel di bawah ini.

Features

  • Layar LCD yang mudah dibaca
  • Kapasitas memori besar untuk penyimpanan data
  • Alarm visual batas atas dan bawah untuk memantau kondisi secara langsung
  • Mode pencatatan Burst dan Statistik untuk analisis data yang lebih detail
  • Sensor kelembapan relatif (RH) dapat diganti oleh pengguna
  • Kompatibel dengan software HOBOware dan HOBOware Pro untuk pengaturan logger, pembuatan grafik, dan analisis data

Specification

Temperature Sensor

Range -20° to 70°C / -4° to 158°F
Accuracy ±0.21°C (0° to 50°C); ±0.38°F (32° to 122°F)
Resolution
0.024°C at 25°C , see manual for plot
0.04°F at 77°F , see manual for plot
Response Time 4 minutes (air moving 1 m/s / 2.2 mph)
Drift <0.1°C per year; 0.18°F per year

RH Sensor

Range 15% to 95% RH (non-condensing)
Accuracy ±3.5% from 25% to 85% including hysteresis at 25°C (77°F); below 25% and above 85% ±5% typical
Resolution 0.07% at 25°C (77°F) and 30% RH
Response Time 43 seconds to 90% (airflow 1 m/s / 2.2 mph)
Drift <1% per year (typical)

Logger

Logger Operating Range
Logging: -20° to 70°C (-4° to 158°F); 0 to 95% RH (non-condensing)
Launch/Readout: 0° to 50°C (32° to 122°F) per USB specification
Logging Rate 1 second to 18 hours, 12 minutes, 15 seconds
Logging Modes Fixed interval (normal), burst, atau statistics
Memory Modes Wrap when full atau stop when full
Start Modes Immediate, push button, date & time, atau next interval
Stop Modes When memory full, push button, atau date & time
Restart Mode Push button
Time Accuracy ±1 minute per month @25°C (77°F)
Power Source One 3V CR2032 lithium battery and USB cable
Battery Life 1 year, typical with logging rate of 1 minute and sampling interval of 15 seconds or greater
Memory 128 KB (84,650 measurements max)
Download Type USB 2.0 interface
Full Memory Download Time 20 seconds
LCD LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range
Size 3.66 × 8.48 × 1.52 cm (1.44 × 3.34 × 0.6 in.)
Weight 30 g (1.06 oz)
Environmental Rating IP50
