HOBO U23 Pro v2 Temperature/Relative Humidity Data Logger

HOBO U23 Pro v2 Temperature/Relative Humidity Data Logger - Image 3

Overview

Data logger tahan cuaca yang dilengkapi sensor suhu dan kelembapan relatif bawaan. Sensor kelembapan relatifnya dirancang dengan daya tahan tinggi, sehingga sangat andal digunakan di lingkungan dengan tingkat kelembapan tinggi.

Informasi Penting:
Memerlukan software HOBOware serta Optic USB Base Station atau HOBO Waterproof Shuttle (U-DTW-1) untuk pengambilan data. Penggunaan HOBOware Pro diperlukan jika menggunakan HOBO Waterproof Shuttle.

Features

Casing tahan cuaca, cocok digunakan di lingkungan luar ruangan atau area dengan kondisi lembap/berembun
Akurasi pengukuran tinggi
Sensor kelembapan relatif dengan respons cepat serta kemampuan pemulihan yang sangat baik setelah kondisi berembun
Versi sensor eksternal berdiameter kecil, ideal untuk pengukuran di ruang sempit
Antarmuka Optic USB untuk proses pengunduhan data yang cepat dan andal
Kompatibel dengan software HOBOware dan HOBOware Pro untuk pengaturan logger, pembuatan grafik, dan analisis data

Specification

Temperature Sensor

Operation Range	U23-001A internal sensor: -40 to 70°C (-40 to 158°F) U23-002A external temperature sensor: -40 to 70°C (-40 to 158°F) U23-003 & U23-004 external sensors: -40 to 100°C (-40 to 212°F); tip & cable immersion in fresh water up to 50°C (122°F) for 1 year
Accuracy	U23-001A & U23-002A: ±0.25°C (-40 to 0°C); ±0.2°C (0 to 70°C) U23-003 & U23-004: ±0.21°C (0 to 50°C); see Plot A
Resolution	U23-001A & U23-002A: 0.04°C (0.072°F) U23-003 & U23-004: 0.02°C at 25°C (0.04°F at 77°F); see Plot A
Response Time (90%)	U23-001A internal sensor: 10 minutes in air moving 1 m/sec U23-002A external temperature sensor: 3 minutes, 45 seconds in air moving 1 m/sec U23-003 and U23-004 external sensors: 3 minutes in air moving 1 m/sec; 30 seconds in stirred water
Drift	U23-001A and U23-002A: <0.01°C (0.018°F) per year U23-003 and U23-004: <0.1°C (0.18°F) per year

Relative Humidity Sensor (U23-001A & U23-002A)

Operation Range	0 to 100% RH, -40° to 70°C (-40° to 158°F) Exposure to conditions below -20°C (-4°F) or above 95% RH may temporarily increase the maximum RH sensor error by an additional 1%
Accuracy	±2.5% from 10% to 90% RH typical to a maximum of ±3.5% including hysteresis at 25°C (77°F); below 10% and above 90% ±5% typical
Resolution	0.05%
Response Time (90%)	U23-001A: 40 minutes (air 1 m/sec, with protective cap) U23-002A: 15 seconds (air 1 m/sec)
Drift	<1% per year (typical)

Logger

Operation Range	-40° to 70°C / -40° to 158°F
Real-time Clock	±1 minute per month 0° to 50°C 32° to 122°F
Battery	1/2 AA 3.6V lithium, user-replaceable (HP-B)
Battery Life	3 years with 1 minute or greater logging interval
Memory	64 KB (±21,000 temperature & RH measurements)
Materials	All models: ASA styrene polymer housing and mounting clamp; polypropylene protective cap; Buna-N o-ring(s); U23-001A, U23-002A only: ASA styrene polymer RH sensor cap; modified hydrophobic polyethersulfone membrane
Cables	U23-001A: No cables U23-002A: One 184 cm (6 ft) PVC cable; sensor diameter 1 cm (0.38 in.) U23-003: Two 184 cm (6 ft) PVC cables; sensor diameter 0.5 cm (0.20 in.) U23-004: One 184 cm (6 ft) PVC cable; sensor diameter 0.5 cm (0.20 in.)
Environmental Rating	Electronics housing: NEMA 6P equivalent (brief submergence) RH models: NEMA 4 equivalent (splash-resistant)
Launch Modes	Immediate start; delayed start
Logging Interval	Fixed-rate or multiple logging intervals, with up to 8 user-defined logging intervals and durations; logging intervals from 1 second to 18 hours
Offload Modes	Offload while logging; stop and offload
Battery Indication	Battery voltage can be viewed in status screen and optionally logged in datafile. Low battery indication in datafile.
Weight	U23-001A: 57 g (1.5 oz); U23-002A: 118 g (3.1 oz); U23-003: 138 g (3.7 oz); U23-004: 102 g (2.7 oz)
Dimensions	Housing measures 10.2 × 3.8 cm 4.0 Ã 1.5 in.
NIST Certificate	Temperature certificate available for additional charge
