PHYSICAL
Length: 18.85 cm (7.42 in)
Length w/splash guard: 19.9 cm (7.87 in)
Width: 16.31 cm (6.42 in)
Height: 4.32 cm (1.70 in)
Weight: 1.0 kg (2.2 lbs)
LED Status Indicators: RFID service, power, PoE,
Ethernet, tag detection, and antenna port connection
status
ENVIRONMENTAL
Operating Temperature: -25 to 55°C (-13 to 131°F)
Storage Temperature: -30 to 70°C (-22 to 158°F)
Relative Humidity: 5% to 95% (non-condensing)
Enclosure: IP53 sealing, Die cast magnesium base, Lexan
plastic cover
CONNECTIVITY
Communications: 10/100 BaseT Ethernet RS-232, USB
for configuration
Input Power: PoE (802.3at compliant) DC power input
(12 VDC +/-5%, 30W), sealed/locking connection.
Requires optional Honeywell 100/240 VAC converter
GENERAL PURPOSE
Input/Output (GPIO): Four input (0 to 40 VDC) and four
output (0 to 48 VDC, 0.25 amp) circuits, powered via PoE
or DC input (500 mA, 12 VDC)
RF CHARACTERISTICS
Antenna Connections: Four reverse-polarity (RP) TNC
ports configurable for mono- or bi- static operation.
Antenna fault detection and auto tuning for best
performance
Output Power: 1 to 30 dBm, configurable in 1 dB steps
(calibrated above 9 dBm)
Frequency Ranges: FCC (902-928 MHz) and
ETSI (865-868 MHz), factory configured
SOFTWARE PLATFORM
Passive UHF Tag Protocols:
ISO 18000-6B
ISO 18000-6C
EPCglobal UHF Class 1 Gen 2
Tag Features:
NXP G2X, Impinj Monza 4QT extensions
High memory tags (Fujitsu, Tego, ATA)
Host Application Protocols:
EPCglobal LLRP
Honeywell Advanced RFID Extensions (ARX)
Honeywell Basic Reader Interface (BRI)
Honeywell Developer Library (IDL) resource
kit for BRI (Java, C# .NET)
Management and Configuration:
Bonjour
Universal Plug and Play (UPnP)
Honeywell SmartSystems client
Honeywell Web Services and Web Configuration Interface
Network Protocols:
HTTP/HTTPS Web Server
IPv4, IPv6
DHCP, DNS, NTP, Syslog
OPTIONAL EXPANDED MEMORY
Support for embedded C# .NET and Java applications
96 MB of flash application memory
96 MB of flash data storage
64 MB of available RAM
SECURITY
FIPS 140-2 compliance for HTTPS, LLRP-secure, and
Web Services (DCWS)-secure
RADIUS client support
SSL Certificate support
ACCESSORIES
Honeywell approved antennas, antenna cables
REGULATORY APPROVALS AND COMPLIANCE
Model: IF2
Safety: IEC/UL 60950-1
EMC: Class B – FCC/ICES/EN
RESTRICTIONS ON USE
Some approvals and features may vary by country and
may change without notice. Please check with your
local sales office for further information.
Features
- Advanced performance in a compact and cost-effective design, with a low cost per read point for superior ROI. Choice of Power over Ethernet lowers cost of installation.
- Easily deployed and managed on common networks service plan.
- Directly monitors and controls peripherals without extra equipment
- Expanded memory option hosts applications written in Java® , Java Script, or C# .Net.
- Factory configurable to operate in world regions supporting FCC or ETSI frequency bands.
