Specifications
Rated Capacities¹ : 100 to 10,000 kN
Over Range : 150% F.S.
Resolution : 0.025% F.S.
Accuracy² : ±0.5% F.S.
Temperature Range : −20°C to +80°C
Internal Diameters¹ : solid, 25, 50, 75, 100, 125, 150, 200, 250 mm
¹Other capacities and diameters available on request. Calibrations that exceed GEOKON’S NIST traceable capacity of approximately 10,675 kN are subcontracted to an accredited testing laboratory.
²Established under laboratory conditions. System accuracy depends on end loading conditions.
