Loadcell B8D stainless steel shear beam load cell, OIML approved (250kg-5t)

Loadcell B8D stainless steel shear beam load cell, OIML approved (250kg-5t) - Image 3

Loadcell B8D stainless steel shear beam load cell, OIML approved (250kg-5t) - Image 4

Loadcell B8D stainless steel shear beam load cell, OIML approved (250kg-5t) - Image 5

Loadcell B8D stainless steel shear beam load cell, OIML approved (250kg-5t) - Image 6

Load Cell, Single Point Load Cell, Sensor Timbangan, Sensor Load Cell, Sensor Timbangan Digital, Jual Sensor Timbangan

Available Models B8D

Technical Specifications B8D

Spesifikasi

Stainless steel IP67 shear beam load cell (250kg is bending beam load cells)
Suitable for floor scales, automobile test facilities, hopper scales and other weighing devices
Current calibrated (sc-option)

Available Models

Capacity Accuracy Full article description
250kg C3/C4/C5 B8D-C3/C4/C5-250kg-6B(-W6)
500kg C3/C4/C5 B8D-C3/C4/C5-500kg-6B(-W6)
1t C3 B8D-C3-1t-6B(-W6)
2t C3 B8D-C3-2t-6B(-W6)
5t C3 B8D-C3-5t-6B(-W6)
