Loadcell HM8 nickel plated alloy steel shear beam load cell, OIML approved (1t-50t)

Loadcell HM8 nickel plated alloy steel shear beam load cell, OIML approved (1t-50t) - Image 3

Loadcell HM8 nickel plated alloy steel shear beam load cell, OIML approved (1t-50t) - Image 4

Loadcell HM8 nickel plated alloy steel shear beam load cell, OIML approved (1t-50t) - Image 5

Load Cell, Single Point Load Cell, Sensor Timbangan, Sensor Load Cell, Sensor Timbangan Digital, Jual Sensor Timbangan

Available Models HM8

Technical Specifications HM8

Spesifikasi

Nickel plated alloy steel IP68 shear beam load cell
Hermetically sealed
Suitable for truck, track, hopper and
other electronic weighing devices

Available Models

Capacity Accuracy Full article description
1t C3 Excluded from OIML HM8-C3-1t-6.5B6
2t C3 Excluded from OIML HM8-C3-2t-6.5B6
2.5t C3 Excluded from OIML HM8-C3-2.5t-6.5B6
3t C3 Excluded from OIML HM8-C3-3t-6.5B6
5t C3 HM8-C3-5t-6.5B6
10t C3 HM8-C3-10t-6.5B6
15t C3 HM8-C3-15t-6.5B6
20t C3 HM8-C3-20t-6.5B6
25t C3 HM8-C3-25t-6.5B6
30t C3 Excluded from OIML HM8-C3-30t-6.5B6
50t C3 Excluded from OIML HM8-C3-50t-6.5B6
