WIRELESS
Radio/Range: 2.4 GHz to 2.5 GHz (ISM Band)
Adaptive Frequency Hopping; Bluetooth v2.1: Class 1:
100 m (300 ft) line of sight
Data Rate (Transmission Rate): Up to 1 Mbps
Battery: 2400 mAh Li-Ion minimum
Number of Scans: Up to 50,000 scans per charge
Expected Hours of Operation: 14 hours
Expected Charge Time*: 4.5 hours
MECHANICAL/ELECTRICAL
Dimensions (L x W x H):
Scanner (1911iER-3): 133 mm x 75 mm x 195 mm
(5.2 in x 2.9 in x 7.6 in)
Charger/Communication Base (COB02/CCB02-
100BT-07N): 250 mm x 103 mm x 65 mm
(9.9 in x 4.1 in x 2.6 in)
Weight:
Scanner: 390 g (13.8 oz)
Charger/Communication Base: 290 g (10.2 oz)
Operating Power (Charging):
Scanner: N/A
Charger/Communication Base: 5 W (1A @ 5 V)
Non-Charging Power:
Scanner: N/A
Charger/Communication Base: 0.6 W
(0.12A @ 5 V)
Host System Interfaces:
Scanner: N/A
Charger/Communication Base: USB, Keyboard
Wedge, RS-232 TTL
ENVIRONMENTAL
Operating Temperature**:
Scanner: -20°C to 50°C (-4°F to 122°F)
Charger/Communication Base: -20°C to 50°C
(-4°F to 122°F)
Storage Temperature:
Scanner: -40°C to 70°C (-40°F to 158°F)
Charger/Communication Base: -40°C to 70°C
(-40°F to 158°F)
Humidity:
Scanner: Up to 95% relative humidity,
non-condensing
Charger/Communication Base: Up to 95% relative
humidity, non-condensing
Drop:
Scanner: Designed to withstand 50 2 m (6.5 ft)
drops to concrete at -20°C (-4°F)
Charger/Communication Base: Designed
to withstand 50 1.2 m (4 ft) drops to concrete
at -20°C (-4°F)
Tumble:
Scanner: 5,000 1 m (3.3 ft) tumbles
Charger/Communication Base: 5,000 1 m
(3.3 ft) tumbles
Environmental Sealing:
Scanner: IP65
Charger/Communication Base: IP51
Light Levels:
Scanner: 0 to 100,000 lux (9,290 foot-candles)
Charger/Communication Base: N/A
ESD:
Scanner: ±20 kV air discharge,
±8 kV contact discharge
Charger/Communication Base: ±20 kV air
discharge, ±8 kV contact discharge
SCAN PERFORMANCE
Scan Pattern: Area Imager (838 x 640 pixel array)
Motion Tolerance: Up to 610 cm/s (240 in/s) at
16.5 cm (6.5 in) and 381 cm/s (150 in/s) at 25 cm
(10 in) for 13 mil UPC
Scan Angle: ER Focus
Horizontal: 31.6°
Vertical: 24.4°
Symbol Contrast: 20% minimum
reflectance difference
Pitch, Skew: 45°, 65°
Warranty: 3-year factory warranty
(Note: Battery warranty is 1-year.)
Features
- The custom-built IP65-rated housing is able to withstand 5,000 1 m (3.3 ft) tumbles and survive 50 drops from 2 m (6.5 ft) at -20°C (-4°F), reducing service costs and increasing device uptime.
- Bluetooth Class 1, v2.1 radio enables movement up to 100 m (300 ft) from the base, and reduces interference with other wireless systems. Up to 7 imagers can communicate with a single base, reducing total cost of ownership.
- The second-generation of the Honeywell TotalFreedom™ area-imaging development platform enables the loading and linking of multiple applications to enhance image decoding, data formatting and image processing – eliminating the need for host system modifications.
- The long-lasting Lithium-Ion battery powers up to 50,000 scans per full charge and is removable without tools, ensuring maximum uptime for operations running multiple shifts.
- With its extended linear depth-of-field, the scanner scans out-of-reach items with ease and allows users to scan 20 mil linear codes out to 75 cm (29.5 in) without sacrificing performance on 2D codes.
