Mechanical
Dimensions (LxWxH) 60 mm x 168 mm x 74 mm (2.3˝ x 6.6˝ x 2.9˝)
Weight 133 g (4.7 oz)
Electrical
Input Voltage 5 V ± 5%
Operating Power 700 mW; 140 mA (typical) @5V
Standby Power 425 mW; 85 mA (typical) @ 5V
Host System Interfaces Multi-interface; includes USB (HID Keyboard, Serial, IBM OEM), RS232 (TTL + 5V, 4 signals), Keyboard Wedge,
RS-232C (± 12V), IBM RS485 supported via adapter cable
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 5% to 95% relative humidity, non-condensing
Drop Designed to withstand 30 drops on concrete from 1.5 m (5’)
Environmental Sealing IP40
Light Levels 0-75,000 Lux (direct sunlight)
Scan Performance
Scan Pattern Single scan line
Scan Angle Horizontal: 30°
Print Contrast 20% minimum reflectance difference
Pitch, Skew 60°, 60°
Decode Capabilities Reads standard 1D and GS1 DataBar symbologies
Warranty 5 year factory warranty
Features
- Extended Depth of Field: Scans out-of-reach items with ease and allows users to scan 13 mil bar codes from as far away as 17.6 inches (447 mm)
- Automatic Interface Detection: Supports all popular interfaces in one device, replacing the time consuming process of scanning programming bar codes with automatic interface detection and configuration
- CodeGate® Technology: Enables users to ensure that the desired bar code is scanned before transmitting data, making the scanner ideal for use in menu scanning applications
- Superior Out-of-Box Experience: Simplifies set up with quick and easy stand assembly; automatic in-stand detection and configuration; increases throughput with true object detection
- Ergonomic Design: Fits comfortably in most hands, reducing user fatigue in scan-intensive applications
- Remote MasterMind™ Ready: Reduces total cost of ownership by providing a turnkey remote device management solution that easily manages and tracks usage of installed devices
