Spesification
| model | PWS-E10(15) | PWS-E25 | PWS-E50 | PWS-E100 | PWS-E250 | PWS-E500 | PWS-E1000 | PWS-E2500 | |
| Maximum test force (KN) | Static | 10(15) | 25 | 50 | 100 | 250 | 500 | 1000 | 2500 |
| dynamic | ±10(15) | ±25 | ±50 | ±100 | ±250 | ±500 | ±1000 | ±2500 | |
| Measurement accuracy | Test force | Better than ±1% of the indication (precise grade ±0.5%) | |||||||
| Displacement | ±1% FS better than the indicated value (precision level ±0.5%FS) | ||||||||
| Deformation | Better than ±1% of the indication (precise grade ±0.5%) | ||||||||
| Frequency range (HZ) | 0.001-75 ( depending on the control system) | ||||||||
| Frame form | Double column | Double column / four column | Four columns | ||||||
| Amplitude (mm) | ±75 | ±75 | ±75 | ±75 | ±75 | ±75 | ±75 | ±75 | |
| Column distance (mm) | 430 | 430 | 530 | 530 | 635 | 850× 500 | 930 × 590 | 1200 × 700 | |
| Test space (mm) | 600 | 600 | 750 | 750 | 1200 | 1500 | 1500 | 1500 | |
