APLIKASI
* Pemantauan lingkungan
* Sistem kontrol rumah kaca
* Pintu & jendela cerdas
* Kotak cahaya pintar
* Peternakan
* Sistem kontrol bangunan cerdas
TECHNICAL SPECIFICATION
|
Item
|
Specifications
|
| Supply Voltage |
12-24VDC
|
| Automatic heating |
heating power:10W max.
|
| Output |
Relay(NO)
|
| Load Capacity(relay) |
AC120V/2A ,DC24V/2A
|
| Coil material |
Gold-plated(Strong corrosion resistance) |
| Ingress protection |
IP67
|
| Operating Temperature |
-30℃-+70℃
|
| Weight(unpacked) |
150g
|
| Dimension |
90*60*40mm
|
| Shell material |
ABS
|
| Storage Condition |
10℃-60℃@20%-90%RH
|
DIMENSION AND MOUNTING
PARAMETER SELECTION TABLE
|
Remark
|
Series
|
Type
|
Supply |
Output |
Cable Length
|
|
|
RK
|
|
|
|
|
|
|
|
|
400
|
|
|
|
|
|
|
|
|
02
|
|
|
|
|
|
|
|
A |
|
|
|
|
|
|
B |
|
|
12-24V |
|
|
|
X |
|
|
Other |
|
|
|
|
A |
|
Relay(NO) default |
|
|
|
|
X |
|
Other |
|
|
|
|
|
|
2000
|
Units:mm（typ.）
|
|
|
|
|
|
|
3000
|
Units:mm
|
|
|
|
|
|
|
…
|
Units:mm
|
Example: RK400-02BAN2000 supply: 12-24V, output:relay(NO), Cable Length:2m.
