Ultrasonic Thickness Gauge TIME 2136

Ultrasonic Thickness Gauge TIME 2136

TIME®2136 advanced ultrasonic thickness gauge features measuring through painted or coated surfaces using a dual element style transducer in echo-echo mode. Its display resolution is precise to 0.001 mm. Automatic probe recognition. This instrument can be used for thickness check of pipelines and pressure vessels, quality control of forging and casting parts, corrosion check of ship walls and bottom, routine maintenance of roads and bridges, etc.

TIME®2136 advanced ultrasonic thickness gauge features measuring through painted or coated surfaces using a dual element style transducer in echo-echo mode. Its display resolution is precise to 0.001 mm. Automatic probe recognition. This instrument can be used for thickness check of pipelines and pressure vessels, quality control of forging and casting parts, corrosion check of ship walls and bottom, routine maintenance of roads and bridges, etc.

Features

  • Measure through coated surfaces and eliminate the thickness of the paint using a dual element style transducer in echo-echo mode
  • Identify the standard transducer automatically, or preset the transducer frequency manually
  • Transducer TSTU17 and TSTU32 are optional to measure various materials
  • Connect to TIME TA230 printer or PC via RS232 interface
  • Upper /lower limits pre-setting and sound alarm
  • Differential mode shows the difference between the test thickness value and the user-setting thickness range.
  • Memory of 500 test data
  • Resolution 0.001mm and 0.01mm selectable for your use



Technical Specification

Measuring range(depends on probe)

Transducer 5PØ10:

1.2-200mm (steel in T-E testing mode)

3~20mm(steel in E-E mode)

Transducer TSTU32:

5mm~300mm(steel in T-E testing mode)

Display resolution

0.001mm or 0.01mm

Sound speed

1000~9999m/s

Display

Backlight

Measuring accuracy

±1%H?0.1mm(H means the thickness of tested plate)

Data output

RS232

Calibration plate

4.0mm(steel)

Power

AA batteries 1.5V (2pcs)

Unit scales

mm/inch

Operating temperature

-10~60?

Dimensions (mm)

152×74×35

Weight (g)

220



Standard Delivery Optional Accessory
Main unit 1 Communication cable
Transducer 5P?10 1 Standard plate
Couplant 1 TIME TA230 printer
Sheath for main unit 1 Transducer TSTU32
TIME certificate 1
Warranty card 1
Instruction manual 1
