Specifications
Range: ±2.5 millivolts to ±5 volts (analog)
DC to 200 kHz (frequency)
DC to 200 kHz (frequency)
Resolution: 0.33 microvolts to 1333 microvolts (analog)
±35 nS/no. cycles measured (frequency)
±35 nS/no. cycles measured (frequency)
Accuracy: ±0.1% F.S. of reading, plus offset (analog)
±0.01% of reading, plus resolution (frequency)
±0.01% of reading, plus resolution (frequency)
Excitation Output: ±2.5 V at 25 mA (maximum),
Frequency Sweep 5 V with AVW200
Frequency Sweep 5 V with AVW200
Battery: 4 × D cell Lithium 8.5 Ah
Temperature Range: −25°C to +50°C (−55°C to +80°C optional)
Diameter × Height: 168 × 381 mm
