Coefficient of Friction Tester MXD-02 Labthink

Features

  • Static and kinetic coefficients of friction can be tested for each specimen
  • This instrument conforms to multiple standards of ISO, ASTM and GB and the user could select testing methods as required
  • Test speed could be preset and adjusted by the users as required
  • Sled of specific weight could be customized
  • The sliding plane and the sled are treated by degaussing and remanence detection which effectively reduce the system error
  • Top quality parts and components made by world famous brands are used to ensure reliable overall product performance
  • The instrument is controlled by micro-computer with LCD display, PVC operation panel and menu interface
  • Professional operating software support statistical analysis of single specimen, group specimens, superposition analysis of test curves and historical data comparison functions
  • Equipped with RS232 port and micro printer port which is convenient to the data transmission and PC connection
  • Supports LystemTM Lab Data Sharing System for uniform and systematic data management

Standards

This instrument conforms to various national and international standards:
ISO 8295, ASTM D1894, TAPPI T816, GB 10006

Applications

Basic Applications
  • Plastic Films and Sheets
    Coefficient of static and dynamic friction tests of plastic films and sheets
  • Paper and Paperboard
    Coefficient of static and dynamic friction tests of paper and paperboard
  • Textiles, Non-woven Fabrics and Woven Bags
    Coefficient of static and dynamic friction tests of textiles, non-woven fabrics and woven bags
  • Rubber
    Coefficient of static and dynamic friction tests of rubber products
  • Aluminum Foils, Aluminum Foil Composite Films, and Metal Products
    Coefficient of static and dynamic friction tests of aluminum foils, aluminum foil composite films and other metal products
  • Printing Matters
    Coefficient of static and dynamic friction tests of printing matters
Extended Applications
  • Wood and Flooring
    Coefficient of static and dynamic friction tests of wood and flooring
  • Photographic Films
    Coefficient of static and dynamic friction tests of photographic films
  • Grains
    Coefficient of static and dynamic friction tests of grains against the metal materials
  • Hair
    Coefficient of static and dynamic friction tests of the hairs
  • Pipes
    Coefficient of static and dynamic friction tests of pipes
  • Ball Shaped Materials
    Coefficient of static and dynamic friction tests of the ball shaped material against even leveled materials
  • Medical Tubes
    Coefficient of static and dynamic friction tests of medical tubes and artificial skin
  • Lacquered Wires
    Coefficient of static and dynamic friction tests of the lacquered wire against even leveled materials

Technical Specifications

Specifications MXD-02 Coefficient of Friction Tester
Capacity Range 0 ~ 5 N
Accuracy 0.5% FS
Stroke 70 mm, 150 mm
Mass of Sled 200 g (Standard)
Sled of specific weight could be customized
Test Speed 100 mm/min, 150 mm/min
Test speed could be adjusted
Environment Condition Temperature: 23±2°C
Humidity: 20%RH ~ 70%RH
Power Supply 220VAC 50Hz / 120VAC 60Hz
Instrument Dimension 630 mm (L) x 360 mm (W) x 230 mm (H)
Net Weight 33 kg

Configurations

Standard Configurations
Instrument, Micro Printer and Sled of 200g
Optional Parts
Professional Software, Communication Cable and Customized Sled of 500g
