Specifications
Standard Ranges¹ : 350, 700 kPa; 1, 2, 3, 5 MPa
Over Range : 150% F.S. (maximum)
Resolution : 0.025% F.S.
Accuracy² : ±0.1% F.S.
Temperature Range¹ : −20°C to +80°C
Height × Diameter¹ : 12 × 230 mm
¹Other ranges and sizes available on request.
²Transducer accuracy established under laboratory conditions.
Total system accuracy (pressure transducer + pressure cell) is subject to site-specific variables.
