Technical Specifications
|
Model |
TIME6203 |
|
|
Test Force |
kgf |
62.5kgf, 100kgf, 125kgf, 187.5kgf, 250kgf, 500kgf, 750kgf, 1000kgf, 1500kgf, 3000kgf |
|
N |
612.9N, 980.7N, 1226N, 1839N, 2452N, 4903N, 7355N, 9807N, 14710N, 29420N |
|
|
Test Range |
3.18～653HBW |
|
|
Hardness Reading |
LCD Display |
|
|
Conversion Scale |
HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS |
|
|
Data Output |
Built-in Printer, RS232 Interface |
|
|
Microscope |
20× Digital Measuring Eyepiece |
|
|
Minimum Division Value of Drum Wheel |
1.25μm |
|
|
Dwell Time |
0~60s |
|
|
Max. Height of Specimen |
225mm |
|
|
Throat |
135mm |
|
|
Power Supply |
AC220V，50Hz |
|
|
Execute Standard |
ISO 6506，ASTM E10-12，JIS Z2243，GB/T 231.2 |
|
|
Dimension |
545×235×790mm，Packing Dimension: 650×435×1060mm |
|
|
Weight |
Net Weight: 130kg，Gross Weight: 160kg |
|
