Application Range
Suitable for ferrous metal, non-ferrous metals, IC thin sections, coatings, ply-metals; glass, ceramics, agate, precious stones, thin plastic sections etc.; hardness testing such as that on the depth and the trapezium of the carbonized layers and quench hardened layers.
Packing List
| Name |
Qty |
Name |
Qty |
| Instrument Main Body |
1 set |
10× Digital Measuring Eyepiece |
1 pc |
| Diamond Vickers Indenter |
1 pc |
20×、40× Objective |
each 1 pc |
| Cross Test Table |
1 pc |
Power Cable |
1 pc |
| Horizontal Regulating Screw |
4 pcs |
Level |
1 pc |
| Fuse 1A |
2 pcs |
Halogen Lamp 12V、15~20W |
1 pc |
| Inner Hexagon Spanner 2.5mm |
1 pc |
Screw Driver |
1 pc |
| Hardness Block 700~800 HV1 |
1 pc |
Hardness Block 400~500 HV5 |
1 pc |
| Anti-dust Cover |
1 pc |
Usage Instruction Manual |
1 copy |
Technical Specifications
|
Model |
TH723 |
TH723Z |
|
|
Test Force |
kgf |
0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf |
|
|
N |
2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N |
||
|
Test Range |
1HV~2967HV |
||
|
Loading Method |
Automatic (Loading/Dwell/Unloading) |
||
|
Shifting between Objective and Indenter |
Manual Shifting |
Automatic Shifting |
|
|
Objective |
20× ，40× |
||
|
Eyepiece |
10× |
||
|
Total Magnification |
200× ，400× |
||
|
Resolution |
0.125μm ，0.0625μm |
||
|
Dwell Time |
0~60s |
||
|
Light Source |
Halogen Lamp |
||
|
X-Y Test Table |
Size: 100×100mm; Travel: 25×25mm; Resolution: 0.01mm |
||
|
Max. Height of Specimen |
170mm |
||
|
Throat |
130mm |
||
|
Power Supply |
AC220V，50Hz |
||
|
Execute Standard |
ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2 |
||
|
Dimension |
530×280×630mm，Packing Dimension:620×450×740mm |
||
|
Weight |
Net Weight: 35kg，Gross Weight: 47kg |
||
