Specifications
Standard Ranges : −100 to 70, 170, 350, 700 kPa; 1, 2, 3, 5, 7.5 MPa
Over Range : 1.5 × rated pressure
Resolution : 0.025% F.S. (minimum)
Accuracy : ±0.1% F.S.
Linearity : <0.5% F.S. (±0.1% F.S. optional)
Temperature Range¹ : −20°C to +80°C
Length × Diameter : 187 × 33.3 mm
¹High temperature versions available on request.
