Specifications
Standard Ranges¹ : 4850-1 | 7.5, 20, 35 MPa
: 4850-2 | 2, 3, 5 MPa
: 4850-2 | 2, 3, 5 MPa
Over Range : 150% F.S.
Resolution : 0.025% F.S.
Accuracy² : ±0.1% F.S.
Temperature Range¹ : −20°C to +80°C
L × W × H¹ : 4850-1 | 200 × 100 × 6 mm
4850-2 | 250 × 150 × 6 mm
4850-2 | 250 × 150 × 6 mm
¹Other ranges and sizes available on request.
²Transducer accuracy established under laboratory conditions.
Total system accuracy (pressure transducer + pressure cell) is subject to site-specific variables.
