Online Ultrasonic Thickness Gauge TIME®2131

Jual Ultrasonic Thickness Gauge | Distributor Alat Uji | Distributor Data Logger Hobo di Indonesia | Distributor Weather Station ( alat ukur cuaca )

TIME®2131 is an innovative and intelligent ultrasonic thickness equipment developed by Beijing TIME High Technology Ltd.. With built-in WIFI module and relying on our online testing system, it can get connected to the wifi network and thus realizes remote control, data sharing, data analysis, report printing, remote video assistance, remote software upgrade, online help and after-sales support through a mobile phone or computer. The stylish design, powerful functions and excellent performance make TIME®2131 a high-end thickness gauge that fully meets your online testing requirements.

Features

● Auto recognition of probe

● Dynamic compensation of measurement error caused by probe change and coupling condition

● Real time display coupling condition

● OLED screen with high contrast and brightness suitable to use in sunlight

● Scanning measuring mode, up to 20 times per second

● I-E testing mode, E-E testing mode and auto mode for option

● Memory of 3000 data: stored in 30 thickness files, 100 thickness values for each file

● Upgrade online, upgrade the firmware of the unit by WIFI or APP

● Dataview available for selection of data store, ZW5P, TSTU32 etc.

Spesifikasi

Measuring range (steel)	5PΦ10, 5PΦ10/90: 1.2-225.0 mm, 7PΦ6: 0.75-60.0 mm, ZW5P: 4.0-80.0 mm, TSTU32: 3.0-300.0 mm
Accuracy (steel)	ZW5P, TSTU32: ±0.10 mm (H<10.00 mm)±(1%H+0.01) mm (H≥10.0 mm) 5PΦ10, 5PΦ10/90, 7PΦ6: ±0.05 mm (H<10.00 mm) ±(0.5%H+0.01) mm (H≥10.00 mm)
Repeatability (steel)	ZW5P, TSTU32: 0.10 mm, 5PΦ10, 5PΦ10/90, 7PΦ6: 0.03 mm
Stability (steel)	ZW5P, TSTU32: 0.10 mm, 5PΦ10, 5PΦ10/90, 7PΦ6: 0.05 mm
Accuracy for wall thickness of curve surface(steel)	±0.1 mm
Sound velocity range (m/s)	508-18699 (m/s)
Accuracy for thickness when change sound velocity	≤±0.5 mm
Resolution	0.1 mm, 0.01 mm, 0.001 mm
Special display	Min. value, Max. Value, Average value
Alarm	Upper, lower limit
Two point calibration	√
mm/inch	√
Indicator for battery power	√
Indicator for coupling condition	√
Memory	6 sound velocity value, 3000 thickness value
Communication	USB or WIFI
Switch off	Auto switch off in 2 minutes if no use
Working environment	Temperature: 0-40℃, Humidity: 90% RH
Memory environment	Temperature: -25-60℃, Humidity: 90% RH
Power	2 pcs AA battery
Working electricity	60 mA (3.0 V)
