BATTERY-FREE
User Indicators: Good Decode LEDs,
Rear View LEDs, Beeper (adjustable tone
and volume), Vibration (optional and
adjustable), Charge Status Indicator
Number of Scans (based on
default settings):
Fully Charged: Typically more
than 450 scans
Ready-to-Go Notification: At least 25
scans (@1 scan/sec)
First Recharge Alert (30%): Typically
occurs after 300 scans ±10%
Second Recharge Alert (10%): Typically
occurs after 400 scans ±10%
Expected Full Charge Time
(completely discharged):
Standard USB: Typically under
120 seconds
Powered USB/External Wall Power
Adapter: Typically under 60 seconds
Expected Ready-to-Go Charge Time:
Standard USB: Typically under
25 seconds
Powered USB/External Wall Power
Adapter: Typically under 15 seconds
Use Time (5 scans/transaction,
1 min/transaction):
Fully Charged: Typically 25
minutes of usage
Ready-to-Go Notification: Typically 5
minutes of usage left
First Recharge Alert (flashing yellow
LED): Typically 10 minutes of usage left
Second Recharge Alert (flashing red
LED): Typically 5 minutes of usage left
Charge Cycles (from completely
discharged): 500,000
WIRELESS
Radio/Range: 2.4 GHz (ISM Band) Adaptive
Frequency Hopping Bluetooth v4.2; Class
2: 10 m (33 ft) line of sight
ENVIRONMENTAL
Scanner:
Operating Temperature: 0°C to 50°C
(32°F to 122°F)
Storage Temperature: -40°C to 70°C
(-40°F to 158°F)
Humidity: 0 to 95% relative humidity,
non-condensing
Drop: Designed to withstand 50 1.8 m
(6 ft) drops to concrete
Environmental Sealing: IP52
Light Levels: 0 to 100,000 lux
(9,290 ft-candles)
Electrostatic Discharge (ESD) (Scanners
and Cradles): ±8 kV indirect coupling
plane, ±15 kV direct air
Charge and Communication Base:
Operating Temperature:
Charging: 0°C to 50°C (32°F to 122°F)
Non-Charging: 0°C to 50°C
(32°F to 122°F)
Storage Temperature: -40°C to 70°C
(-40°F to 158°F)
Humidity: 0 to 95% relative humidity,
non-condensing
Drop: Designed to withstand 50 1 m
(3.3 ft) drops to concrete
Environmental Sealing: IP41
Light Levels: N/A
MECHANICAL/ELECTRICAL
Scanner:
Dimensions: 104 mm x 71 mm x 160 mm
(4.1 in x 2.8 in x 6.3 in)
Weight: 195 g (6.9 oz)
Operating Power: N/A
Non-Charging Power: N/A
Host System Interface: N/A
Charge and Communication Base:
Dimensions: 132 mm x 102 mm x 81 mm
(5.2 in x 4 in x 3.2 in)
Weight: 180 g (6.3 oz)
Operating Power: 5W (1A @ 5V)
Non-Charging Power: 0.5W (0.1A @ 5V)
Host System Interface: USB, Keyboard
Wedge, RS-232, IBM 46xx (RS485)
SCAN PERFORMANCE
Scan Pattern: Area Image
(1280 x 800 pixel array)
Motion Tolerance: Up to 400 cm/s
(157 in/s) for 13 mil UPC at optimal focus
Scan Angle:
HD: Horizontal: 48°; Vertical: 30°
SR: Horizontal: 48°; Vertical: 30°
Symbol Contrast: 20% minimum
reflectance difference
Roll, Pitch, Skew: ±360°, ±45°, ±65°
Decode Capabilities: Reads standard 1D,
PDF, 2D, Postal Digimarc, DotCode, and
OCR symbologies
(Note: Decode capabilities dependent
on configuration.)
Warranty:
Scanner: Three-year factory warranty
Supercapacitor: Five-year
factory warranty
Features
- When fully charged, the scanner can typically scan over 450 UPC/EAN codes without the need for recharging. The scanner is useable in less than 20 seconds.
- Supercapacitors hold their charge for hours when fully charged. So clinicians who forget to place their scanner in the charger prior to break won’t impact operations upon return.
- Two independently configurable recharge alerts remind clinicians to place the scanner back into the base for charging, ensuring continuous operation.
- The Xenon XP 1952h-bf scanner is fully charged in under 60 seconds when a powered USB or external power supply is used and under two minutes with a simple USB connection.
- When the scanner is placed in the base, the ready-to-scan LED typically flashes in less than 20 seconds to notify the clinician that there is sufficient power to support over 100 scans.
