PT5100 Shearbeam

Overview

Specifications
Output	2.0 mV/V
Zero Balance	±1% FSO
Non-linearity	±0.02% FSO
Hysteresis	±0.02% FSO
Repeatability	±0.02% FSO
Creep (30 min)	±0.02% FSO
Temp. Effect on Zero	±0.02% FSO / 10°C
Temp. Effect on Output	±0.02% FSO / 10°C
Input Resistance	385 ± 10 Ω
Output Resistance	350 ± 5 Ω
Insulation Resistance	> 5000 MΩ
Recommended Excitation	5 – 10 VDC
Maximum Excitation	15 VDC
Safe Overload	150% Rated Capacity
Ultimate Overload	200% Rated Capacity
Operating Temperature Range	-20°C to +60°C
Storage Temperature Range	-30°C to +70°C
Cable Length	3 m
Protection Class	IP65
