| DC Amperage (bi-polar) |
| Measurement range: +/- 2 to +/- 200 (via span adjust) |
| Accuracy (below 100A span): +/- .5 A |
| Accuracy (above 100A span): +/- .5% full scale |
| Sensor supply: 12 – 24 DC (15 VDC min. for currents > 120 A), 35 mA no-load to 110 mA at 200 A current |
| Isolation: 600 VAC rms |
| Operating temperature range: -30 to 60C (-22 to 140F) |
| Humidity range: 10 – 90% non-condensing |
| Response time: 2 sec. |
| Output: (bi-polar) 4 – 20mA |
| Dimensions: 3.1×2.8×1.4 in. (79x70x36 mm) |
| Weight: 5.25 oz. |
| Sensor opening: 1.1x.9 in. (28×23 mm) |
| LED indications: single green blink=Norm, double green=Over Span, red+green=Over Limit, solid red=overload |
| CE, UL |
