The multi-functional TIME®2430 ultrasonic thickness gauge is made with special waterproof and oil-resistant high-density plastic shell and rubber buttons. It contains almost all the common thickness measurement functions. Most importantly, its echo-echo testing mode enables measuring through painted or coated surfaces and on-site quick nodularity measurement in Cast Iron as well. This handheld ultrasonic gauge is widely used in oil and gas equipments, petrochemical facilities, pipelines, pressure vessels, special inspection and nondestructive testing of new materials, etc.
Features
● Two optional transducers: echo-echo transducer and straight transducer
● With the function of echo-echo (E-E) measurement and auto gain control (AGC), thickness of substrate is attainable, even with the cover coating
● Quickly measure the degree of nodularity in cast iron
● Double crystal lemo probe or high frequency single crystal probe for option
● Sound alarm and differential modes are available
● Three-color indication and buzz alarm
● High frequency scanning technique available
● Superior waterproof and dustproof plastic shell
● Six languages and presetting auto shutdown function for your convenience
● Three colors indication and buzz alarm
Spesifikasi
|
Measurement range |
0.6mm-508mm |
|
Velocity range |
600-16000m/s |
|
Measurement rate |
4/s and 20/s in fast mode |
|
Bandwidth |
500K-12MHz (-3dB) |
|
Resolution |
0.01mm(0.001″), 0.1mm (0.01″) |
|
Velocity calibration range |
0.508mm/μs～18.699mm/μs |
|
Display |
128×64 Graphics LCD monochrome |
|
Battery life |
Up to 200 hours |
|
Operating |
-10℃～50℃ |
|
Dimensions (mm) |
127x76x32 |
|
Weight (g) |
230 |
